Benchtop Pulse Vacuum Autoclave

YBOTECH BTA Series Benchtop Pulse Vacuum Autoclave/Sterilizer is a safe and reliable B-class rapid sterilizer, the use of saturated steam as the sterilization medium, through the way of pulsating vacuum, the saturated steam is completely penetrated to the surface of the items. So as to use the release of latent heat to kill all microorganisms, is the most reliable way of physical sterilization.

The sterilizer is suitable for medical, pharmaceutical, scientific research, stomatology, ophthalmology and other units. Providing rapid sterilization fro ophthalmic instruments, dental instruments, glassware, fabric dressings and other articles.

Inquire
Brochure Download
Features
  • Stainless steel structure: High-quality stainless steel 304/316L are optional, corrosion resistance, easy maintenance, long life span.
  • Manual opening door: Flat open manual opening structure, self-expanding seal, simple operation.
  • Built-in multiple programs: Built-in multiple sterilization programs for instruments, utensils, fabrics, etc.
  • Intelligent control system: Microcomputer program automatic control, LCD touch screen.
  • Power off hold system: Power off hold function, after re-connecting the power, automatically resume from the program break-point.
  • Safety protection system: Over-temperature protection, anti-dry burning protection, door safety interlock, automatic pressure relief.
  • Over-pressure protection: Automatic relief protection of safety valve when the pressure exceeds the working pressure.
  • Vacuum drying system: Fabric dryness is less than 1%, instrument dryness is less than 0.1%.
Technical Parameters
  • Design pressure: -0.1/0.3MPa;
  • Rated working pressure: 0.23MPa;
  • Ultimate vacuum: -0.096MPa;
  • Pressure display accuracy: 0.1kpa;
  • Sterilization temperature: 105~136℃;
  • Temp.display accuracy: 1 ℃;
  • Maximum temperature: 144℃;
  • Temperature uniformity: ≤±5℃;
  • Time of sterilization:0~60 min;
  • Time of drying:0~60 min;
  • Basket: SUS304, 2pcs.
Basic Specifications
Model Volume

(L)

 Chamber Size Overall Size Weight

(Kg)

 Power
ΦxL (mm) LxWxH (mm)
BTA.B18L 18 250×350 585x515x450 55 220V, 50Hz, 1.7Kw
BTA.B24L 24 250×450 685x515x450 65 220V, 50Hz, 2.0Kw
BTA.B29L 29 316×420 650x640x550 80 220V, 50Hz, 3.0Kw
BTA.B45L 45 316×618 830x640x550 115 220V, 50Hz, 3.6Kw
BTA.B60L 60 385×595 1002x730x560 160 220/380V, 50Hz, 6.6Kw
BTA.B80L 80 385×717 1002x730x600 180 220/380V, 50Hz, 6.67Kw
