eQ1600 Real-time PCR System

Ultrassay eQ1600 Real-time PCR System is mainly used for disease prevention and control, inspection and quarantine, agriculture and forestry, food safety testing, African swine fever (ASF); molecular biology teaching and research; battlefield, criminal investigation and emergency detection; clinical diagnosis, community medical, POCT on-site inspection.

Its main features are strong fluorescence signal, low background noise, high sensitivity, friendly software interface, built-in ultraviolet disinfection and so on.

Inquire
Brochure Download
gradeApplication Field
gradeRigorous Experimental Verification
Technical Specification
Model eQ162C eQ162CP eQ164CP
Sample volume 16*0.2ml single tube or 8-strip transparent tube (except for white opaque tube), you can mark the tube with markers on the cover of the tube.
Applicable reagents This system is an open platform, suitable for various real-time PCR reagents, including fast extraction reagents, non-extraction reagents, or direct amplification reagents and other low-concentration PCR reagent.
Reaction volume 5-100ul
Dynamic range 1-1010 Copies
Color wavelength 400 – 700nm
Optical sensor PD
Dyes CH1: FAM, SYBR Green I;CH2: HEX, JOE, VIC, ROX. CH1: FAM, SYBR Green I;CH2: HEX, JOE, VIC, ROX; CH3: ROX, CALRED; CH4: CY5, QUASAR
Sensitivity 1 Copy
Rn
CV
Block setting range 10-99.9
Temperature control mode Tube mode, Real temperature of simulated reagent
Refrigeration Peltier
Precision of temperature control 0.1
Display resolution 0.1
Temperature accuracy 0.2
Temperature uniformity 0.2
Max. ramping rate 4
Avg. ramping rate 2.5 (50 – 90)
Hot lid 30-105
Operating system Windows 7/10
Communication Interface RS232/USB
Software functions Built-in two-steps, three-steps, LAMP, RPA methods’ PCR program templates, free extraction reagent PCR program template and other common ones.It has functions of system setting (password permission), experimental parameter settings, sample information input, operation management, data export EXCEL, general view of PCR program, real-time amplification curve display, channel crosstalk correction, criterion setting, automatic report, curve capture, etc.
Analytical function Standard curve, relative quantitative curve and melting curve (HRM)
Operating ambient Ambient temperature: 10-30, relative humidity: 20-85% RH,
Input power 100-240V – 300VA
Dimension 324x212x122 (A4 paper size)
Net weight 5.8kg
