YBOTECH LED Overhead Stirrer is used for standard mixing of the higher viscosity substances. They essentially are mixers, used for suspending, gas intrusion and recirculation.
Overhead Stirrers are competent for most demanding tasks with guaranteed safety and performance. They are widely used in chemical synthesis, pharmaceutical synthesis, physical and chemical analysis, petrochemical industries, etc.
| Specifications | OS20-S | OS40-S |
| Max. stirring quantity(H2O) | 20L | 40L |
| Motor type | brushless DC motor | brushless DC motor |
| Motor input power | 60W | 120W |
| Motor output power | 50W | 100W |
| Voltage | 100-240V, 50/60 Hz | 100-240V, 50/60 Hz |
| Power | 70W | 130W |
| Speed range | 50-2200rpm | 50-2200rpm |
| Speed display accuracy | ±3rpm | ±3rpm |
| Speed display | LED | LED |
| Overload protection display | LED lights | LED lights |
| Max. torque | 40Ncm | 60Ncm |
| Viscosity max. | 10000mPas | 50000mPas |
| Chuck range diameter | 0.5-10mm | 0.5-10mm |
| Dimension[WxHxD] | 83x.220x186mm | 83x.220x186mm |
| Weight | 2.8kg | 2.8kg |
| Protection class | IP42 | IP42 |
| Permissible ambient temperature and humidity | 5-40°C 80%RH | 5-40°C 80%RH |
