YBOTECH MicroPette Plus is a fully autoclavable pipette which commonly used in chemistry, biology and medicine to transport a measured volume of liquid, often as a media dispenser. Pipettes come in several designs for various purposes with differing levels of accuracy and precision, from single piece glass pipettes to more complex adjustable or electronic pipettes. Many pipette types work by creating a partial vacuum above the liquid-holding chamber and selectively releasing this vacuum to draw up and dispense liquid. Measurement accuracy varies greatly depending on the instrument.
Main Feature
- Fully autoclavable
- Ergonomic design provides excellent operating experience
- Easy-to-read volume display
- The pipettes cover the volume range from 0.1μL to 5mL
- Easy calibration and maintenance
- Manufactured from innovative materials
- Each MicroPette Plus supplied with an individual calibration certificate according to ISO8655
Specification of Adjustable Pipettes
| Single-channel Adjustable Pipettes | ||||||
| Volume Range | Increment | Test Volume | Accuracy error | Precision error | ||
| % | μl | % | μl | |||
| 0.1-2.5μl | 0.05μl | 2.5 | 2.50% | 0.0625 | 2.00% | 0.05 |
| 1.25 | 3.00% | 0.0375 | 3.00% | 0.0375 | ||
| 0.25 | 12.00% | 0.03 | 6.00% | 0.015 | ||
| 0.5-10μl | 0.1μl | 10 | 1.00% | 0.1 | 0.80% | 0.08 |
| 5 | 1.50% | 0.075 | 1.50% | 0.075 | ||
| 1 | 2.50% | 0.025 | 1.50% | 0.015 | ||
| 2-20μl | 0.5μl | 20 | 0.90% | 0.18 | 0.40% | 0.08 |
| 10 | 1.20% | 0.12 | 1.00% | 0.1 | ||
| 2 | 3.00% | 0.06 | 2.00% | 0.04 | ||
| 5-50μl | 0.5μl | 50 | 0.60% | 0.3 | 0.30% | 0.15 |
| 25 | 0.90% | 0.225 | 0.60% | 0.15 | ||
| 5 | 2.00% | 0.1 | 2.00% | 0.1 | ||
| 10-100μl | 1μl | 100 | 0.80% | 0.8 | 0.15% | 0.15 |
| 50 | 1.00% | 0.5 | 0.40% | 0.2 | ||
| 10 | 3.00% | 0.3 | 1.50% | 0.15 | ||
| 20-200μl | 1μl | 200 | 0.60% | 1.2 | 0.15% | 0.3 |
| 100 | 0.80% | 0.8 | 0.30% | 0.3 | ||
| 20 | 3.00% | 0.6 | 1.00% | 0.2 | ||
| 50-200μl | 1μl | 200 | 0.60% | 1.2 | 0.15% | 0.3 |
| 100 | 0.80% | 0.8 | 0.30% | 0.3 | ||
| 50 | 1.00% | 0.5 | 0.40% | 0.2 | ||
| 100-1000μl | 5μl | 1000 | 0.60% | 6 | 0.20% | 2 |
| 500 | 0.70% | 3.5 | 0.25% | 1.25 | ||
| 100 | 2.00% | 2 | 0.70% | 0.7 | ||
| 200-1000μl | 5μl | 1000 | 0.60% | 6 | 0.20% | 2 |
| 500 | 0.70% | 3.5 | 0.25% | 1.25 | ||
| 200 | 0.90% | 1.8 | 0.30% | 0.6 | ||
| 1000-5000μl | 50μl | 5000 | 0.50% | 25 | 0.15% | 7.5 |
| 2500 | 0.60% | 15 | 0.30% | 7.5 | ||
| 1000 | 0.70% | 7 | 0.30% | 3 | ||
Specification of Fixed Volume Pipettes
| Fixed Volume Pipettes | |||||||
| Volume Range | Increment | Test Volume | Accuracy error | Precision error | |||
| % | μl | % | μl | ||||
| 5μl | – | 5μl | 1.3% | 0.065 | 1.2% | 0.06 | |
| 10μl | – | 10μl | 0.8% | 0.08 | 0.8% | 0.08 | |
| 20μl | – | 20μl | 0.6% | 0.12 | 0.5% | 0.1 | |
| 25μl | – | 25μl | 0.5% | 0.125 | 0.3% | 0.075 | |
| 50μl | – | 50μl | 0.5% | 0.25 | 0.3% | 0.15 | |
| 100μl | – | 100μl | 0.5% | 0.5 | 0.3% | 0.3 | |
| 200μl | – | 200μl | 0.4% | 0.8 | 0.2% | 0.4 | |
| 250μl | — | 250μl | 0.4% | 1.0 | 0.2% | 0.5 | |
| 500μl | – | 500μl | 0.3% | 1.5 | 0.2% | 1.0 | |
| 1000μl | – | 1000μl | 0.3% | 3.0 | 0.2% | 2.0 | |
| 2000μl | – | 2000μl | 0.3% | 6.0 | 0.15% | 3.0 | |
| 5000μl | – | 5000μl | 0.3% | 15 | 0.15% | 7.5 | |
