NE900 Fluorescence Microscope

YBOTECH NE900 Fluorescence Microscope (biological microscope) is and upright research microscope whicch designed to present a safe, comfortable and efficiency observation experience for users. With perfectly performed structure, high-definition optical image and simple operating system, NE900 realizes professional analysis, and meets all the needs of research in scientific, medical and other fields.

Feature
gradeAccurate Imaging, High Color Reduction

Ybotech NE900 series upright biological microscopy adopts NIS infinite for optical system, which has been studied for many years and constantly improved. It has excellent optical quality, such as long working distance, strong color difference correction ability and so on.

gradeErgonomic Design, Comfortable Operation

Laborator y & Inspection and screening work means that microscopes need to be used for a long time. Ybotech NE900 series microscope adopts ergonomic design and man-machine design to reduce muscle tension and visual fatigue caused by repetitive operation, and to make boring work easier and easier.

gradeModular Design to Realize the Diversity of the Observation Method

Ybotech NE900 series microscope adopts modular design, which can realize the observation methods of field, dark field, DIC, fluorescence, polarized light and so on. It is a perfect tool for experimental teaching, scientiÞc research and medical examination.

gradeEnergy Conservation and Environment Protection, Increasing Service Life

The transmitted light would be off automatically after 30 minutes from operators leave. It can not only save energy, but also keep the lamp life.

Technical Specification of NE900 Fluorescence Microscope

NE900 Series Specifications
NE910 NE930 NE950
Main Body Optical System Infinite Optical System
Eyepiece SW10x/25, SW10x/22, EW12.5x/17.5, WF15x/16, WF20x/12
Focusing System Coaxial Coarse and Fine Adjustment, Fine Division 1 um, Moving Range 35mm
Illumination 12V/100W Halogen Lamp

3W S-LED Lamp

Viewing Head – GC900B Seidentopf Binocular Viewing Head;

– GC900 Seidentopf Trinocular Viewing Head, Eyepiece/Port: 100/0, 20/80, 0/100

Inclined at 30°, Interpupillary Distance 47-78mm

– GC900E-1/-2 Ergo Tilting Trinocular Viewing Head, Eyepiece/Port: 100/0, 20/80, 0/100

Adjustable from 0° to 35°, Interpupillary Distance 47-78mm



Nosepiece SZ21A

Sextuple Nosepiece

SZA20A

Motorized Sextuple Nosepiece

Stage – PT6A-L/R Stage with Gorilla Glass Insert

– PT6B-L/R Stage with Sapphire Glass Insert

Moving distance:78(X)x32(Y)mm, 1mm/grid, precision: 0.1mm;

The stage control knobs can be adjusted up or down by 18mm, and with adjustable tension control;

The convex spot design on clip is convenient to place slides with one hand.

Condenser – SJ5 Swing-out Condenser

– XC8 Turret PH Condenser

-DFC Dry Dark-field

Condenser

DFC-O Oild Dark-field

Condenser

-SJ7 Motorized Condenser
Epi-Fluorescent Attachment -FL-VI Epi-Fluorescent Attachment
Fluorescent Illumination – Osram Mercury Lamp HBO 100W

– Metal halide illumination 75W

– LED FL

Optional observation

model

Bright field, Dark field, Phase contrast, Fluorescence, Polarization, DIC
