YBOTECH TopPette single-channel is commonly used in chemistry, biology and medicine to transport a measured volume of liquid, often as a media dispenser. Pipettes come in several designs for various purposes with differing levels of accuracy and precision, from single piece glass pipettes to more complex adjustable or electronic pipettes. Many pipette types work by creating a partial vacuum above the liquid-holding chamber and selectively releasing this vacuum to draw up and dispense liquid. Measurement accuracy varies greatly depending on the instrument.
Main Feature
- Lightweight, ergonomic, low force design
- Digital display clearly reads volume setting
- The pipettes cover volume range of 0.1μl to 10m
- Easy to calibrate and maintain with tool supplied
- Design helps avoid repetitive strain injuried
- Calibrated in accordance with ISO8655. Each pipette supplied with individual test certificate
- The low part is available for autoclaving
Technical Specification
| Single-channel Adjustable Pipettes | ||||||
| Volume Range | Increment | Test Volume | Accuracy error | Precision error | ||
| % | μl | % | μl | |||
| 0.1-2.5μl | 0.05μl | 2.5 | 2.50% | 0.0625 | 2.00% | 0.05 |
| 1.25 | 3.00% | 0.0375 | 3.00% | 0.0375 | ||
| 0.25 | 12.00% | 0.03 | 6.00% | 0.015 | ||
| 0.5-10μl | 0.1μl | 10 | 1.00% | 0.1 | 0.80% | 0.08 |
| 5 | 1.50% | 0.075 | 1.50% | 0.075 | ||
| 1 | 2.50% | 0.025 | 1.50% | 0.015 | ||
| 2-20μl | 0.5μl | 20 | 0.90% | 0.18 | 0.40% | 0.08 |
| 10 | 1.20% | 0.12 | 1.00% | 0.1 | ||
| 2 | 3.00% | 0.06 | 2.00% | 0.04 | ||
| 5-50μl | 0.5μl | 50 | 0.60% | 0.3 | 0.30% | 0.15 |
| 25 | 0.90% | 0.225 | 0.60% | 0.15 | ||
| 5 | 2.00% | 0.1 | 2.00% | 0.1 | ||
| 10-100μl | 1μl | 100 | 0.80% | 0.8 | 0.15% | 0.15 |
| 50 | 1.00% | 0.5 | 0.40% | 0.2 | ||
| 10 | 3.00% | 0.3 | 1.50% | 0.15 | ||
| 20-200μl | 1μl | 200 | 0.60% | 1.2 | 0.15% | 0.3 |
| 100 | 0.80% | 0.8 | 0.30% | 0.3 | ||
| 20 | 3.00% | 0.6 | 1.00% | 0.2 | ||
| 50-200μl | 1μl | 200 | 0.60% | 1.2 | 0.15% | 0.3 |
| 100 | 0.80% | 0.8 | 0.30% | 0.3 | ||
| 50 | 1.00% | 0.5 | 0.40% | 0.2 | ||
| 100-1000μl | 5μl | 1000 | 0.60% | 6 | 0.20% | 2 |
| 500 | 0.70% | 3.5 | 0.25% | 1.25 | ||
| 100 | 2.00% | 2 | 0.70% | 0.7 | ||
| 200-1000μl | 5μl | 1000 | 0.60% | 6 | 0.20% | 2 |
| 500 | 0.70% | 3.5 | 0.25% | 1.25 | ||
| 200 | 0.90% | 1.8 | 0.30% | 0.6 | ||
| 1000-5000μl | 50μl | 5000 | 0.50% | 25 | 0.15% | 7.5 |
| 2500 | 0.60% | 15 | 0.30% | 7.5 | ||
| 1000 | 0.70% | 7 | 0.30% | 3 | ||
| 2-10ml | 0.1ml | 10ml | 0.60% | 60 | 0.20% | 20 |
| 5ml | 1.20% | 60 | 0.30% | 15 | ||
| 2ml | 3.00% | 60 | 0.60% | 12 | ||
| Fixed Pipettes | |||||||
| Volume Range | Increment | Test Volume | Accuracy error | Precision error | |||
| % | μl | % | μl | ||||
| 5μl | – | 5μl | 1.3% | 0.065 | 1.2% | 0.06 | |
| 10μl | – | 10μl | 0.8% | 0.08 | 0.8% | 0.08 | |
| 20μl | – | 20μl | 0.6% | 0.12 | 0.5% | 0.1 | |
| 25μl | – | 25μl | 0.5% | 0.125 | 0.3% | 0.075 | |
| 50μl | – | 50μl | 0.5% | 0.25 | 0.3% | 0.15 | |
| 100μl | – | 100μl | 0.5% | 0.5 | 0.3% | 0.3 | |
| 200μl | – | 200μl | 0.4% | 0.8 | 0.2% | 0.4 | |
| 250μl | — | 250μl | 0.4% | 1.0 | 0.2% | 0.5 | |
| 500μl | – | 500μl | 0.3% | 1.5 | 0.2% | 1.0 | |
| 1000μl | – | 1000μl | 0.3% | 3.0 | 0.2% | 2.0 | |
| 2000μl | – | 2000μl | 0.3% | 6.0 | 0.15% | 3.0 | |
| 5000μl | – | 5000μl | 0.3% | 15 | 0.15% | 7.5 | |
