Ultrassay® UV transilluminator is used in molecular biology laboratories to view DNA or RNA that has been separated by electrophoresis through an agarose gel. Exposing the stained gel to a UV light source causes the DNA to fluoresce and become visible. These instruments are useful for viewing samples to size a PCR product, purify DNA segments after a restriction enzyme digest, quantify DNA, or verify RNA integrity after extraction.
Features
- UV glue: Special UV filter glass, good permeability, high sensitivity enhance the ability to capture weak band signals;
- Precise sealing structure: Effectively reduce gel contamination and internal damage caused by leakage, standard 302mm UV wavelength lamp;
- UV light tube: Reasonable structure design, strong and uniform ultraviolet rays, excellent fluorescence effect;
- Power Switch: Using high-quality switching power supply, stable and reliable long-term operation;
- Protection Cover: Can be freely adjusted and positiooned within 0~180C to ensure optimal UV protection;
- Cooling Fans: Comes with fan cooling device to prolong the service life of the machine.
Applications
Compatible with fluorescent dyes include GeneGreen, GelRed, GelGreen, SYBR Green, SYBR Safe, Goldview, SYBR Gold, SYPRO Ruby, SYPRO Orange, SYPRO Tangerine, eGFP, Cy2, FITC, EB etc.
Product Specification
| Model | UB-TI302 |
| Dimension | L265 * W335 * H120mm |
| View Area | W195 * L145mm |
| Weight | 5.0kg |
| Power Supply | 100~240V 50/60Hz 1A |
| Power Consumption | 8W * 6 |
| Wavelength | 302nm (Standard), 254/354nm (Optional) |
